Monster 12 GPM Bare Pump - 1hp, 230/460V 3-Phase

The Monster 12 GPM Bare Pump in 3 Phase is built for permanent installation in industrial shops, processing facilities, and commercial operations running 230/460V 3 Phase power. The GSM25 cast-iron pumphead moves 12 GPM of motor oil, gear oil, and medium viscosity fluids at 1770 RPM. No handle, no pre-wired switch - this unit ships ready for hardwiring into your panel or control system.

This configuration pairs the GSM25 pumphead with a stock US Made Baldor motor at 1HP and 1770 RPM, wound for 3-Phase power. If you are running a fixed installation where the pump will be wired directly into a control panel, skid, or shop infrastructure, this is the right configuration. The lower RPM relative to the 3450 RPM single phase units means more torque per revolution, well suited for sustained runs on medium viscosity fluids. If you need a plug-and-pump portable unit with a handle and pre-wired switch, see the Monster 12 GPM Portable Pump series instead.

The GSM25 Pumphead

The GSM25 is a direct drive, cast-iron positive displacement gear pumphead with helical cut steel gears. It is self priming, delivers fast and pulseless fluid transfer, and relies on the fluid itself for internal gear lubrication. Viton seals provide compatibility with vegetable oils, motor oils, gear oils, and other medium viscosity fluids.

The Motor

Stock US Made Baldor motor, 1HP, 1770 RPM, 230/460V 3 Phase, NEMA 56C frame. Ships bare, no switch, no cord, no handle. Requires hardwiring by a qualified electrician into a 3 3Phase power source.

Specifications

• SKU: W2089
• Pumphead: GSM25 Cast-Iron Positive Displacement Gear Pump
• Motor Speed: 1770 RPM
• Flow Rate: 12 GPM
• Self-Priming: Yes
• Port Size: 1" NPT Inlet / Outlet
• Seals: Viton (high-temp)
• Motor: 1 HP, 230/460V 3 Phase, NEMA 56C
• Wiring: None - requires custom hardwiring into 3 Phase panel
• Handle: Not included (bare pump)
• Viscosity: Medium viscosity oils

What's in the Box

• GSM25 Cast-Iron Gear Pumphead
• US-Made Baldor Motor (1 HP, 1770 RPM, 3 Phase)
• Three piece shaft coupler with rubber element
• Two (2) 1" NPT to 1.25" Hose Barbs

Note: Hoses and wands are sold separately. This unit is configured for 3 Phase power only and requires hardwiring by a qualified electrician. Not suitable for single-phase residential or standard commercial power.
