Industrial 25 GPM Processing Pump - 3hp, 230/460V 3-Phase

The ultimate heavy-duty transfer system. We pair our flagship cast-iron positive displacement pumphead with an industrial-grade US-made Baldor motor for continuous fluid processing of specialized applications at a reliable 25 GPM.

Engineered to provide a truly robust, high-volume transfer solution, the Industrial Processing Series is built modularly. By combining a dedicated, heavy-duty fluid pumphead with an industrial-grade electric motor, we've created a self-priming, continuous-duty system built to excel in demanding environments.

The Heart + The Muscle

Our pumps are designed as true fluid transfer systems by pairing a specialized pumphead (The Heart) with a powerful electric motor (The Muscle). This allows us to create the perfect tool tailored for your specific viscosity and application needs.

Component 1: Pressure-Relief Pumphead

At the heart of the system is our industrial cast-iron positive displacement gear pumphead featuring an integrated pressure relief valve. Designed specifically for processing applications, this head prevents deadheading when pushing fluids through filtration systems or centrifuges.

Component 2: Industrial Electric Motor

Because moving thicker fluids efficiently requires substantial torque, we match the pumphead with a power plant built to handle the load. This assembly features a Stock US-Made Baldor Motor, providing an excellent foundation for hardwiring into a custom skid or shop infrastructure.

Motor Specifications

System Performance

• System Flow Rate: 25 GPM
• Pump Design: Positive Displacement Gear Pump
• Self-Priming: Yes
• Port Size: 1" NPT Inlet / Outlet

What’s Included

• Industrial Pressure-Relief Pumphead
• US-Made Baldor Electric Motor (3hp)
• Three-piece shaft coupler with rubber element
• Heavy-duty Industrial Baseplate
• Two (2) 1" NPT to 1.25" Hose Barbs

Note: Hoses and wands are sold separately.
